Detail SWRO UNIT 100M3/ DAY
Machine Performance:
Clean Water Production Capacity 4200 litre per hour,
Input water quality TDS < 35.000PPM ( recommended)
Output water quality TDS < 400 PPM,
Salt Rejection Rate 98% ,
Recovery Rate( pure water : inlet water) 50~ 75%
Input Power( standard) AC380V / 50Hz
Pre-treatment Filtration:
By Activated Carbon 30" x 70" - 1 Unit
By Activated Ziolite 30” x 70” – 1 Unit
Micron-Filtration- PVC Multi-Catridges 20" - 7 PCS Catridges
Main unit:
First stage Pump for Prefilter Pump SUS-316 4HP x 380V
High Pressure Booster pump ( Plunger Piston Pump ) <17 KW x 380V
Membrane SW 8" x 40" 6 PCS
Hi-Pressure Membrane Housing 8” x 80” -3 Unit or 8”x 120”- 2 Unit
Main frame steel coating
Accessories
Piping Low pressure: PVC quick connection ,
For Hi-pressure Using Hose, Electrical Parts
Flow metre, TDS metre, pressure metre, electromagnetic valve, etc.
and built-in RO membrane washing device,
Total Weight : Approx. < 2500 Kgs
PRICE EXCLUDE :
